Plans Aircraft-Drawings-Rutan"Quickie"-Homebuilt Airplane Drawings PDF

Description

Aircraft Plans-Drawings-Rutan"Quickie"-Homebuilt

Airplane
Drawings PDF Download.

This listing is for DIGITAL AIRCRAFT PLANS.

NO physical item will be shipped.

You will receive a set of historical aircraft drawings for the ultralight
airplane Rutan"Quickie"

These plans are perfect for aviation enthusiasts, homebuilders, model
makers, and collectors.

WHAT’S INCLUDED:

• Original aircraft drawings and technical sketches • PDF

• General arrangement views

• Structural details (fuselage, wing, tail)

FILE FORMAT:

• PDF / JPG

1.manual_quickie-PDF

2.motor-PDF

3.Q1Plans-PDF

DELIVERY:

• Instant digital download

• Files will be sent via eBay messages after purchase

IMPORTANT:

• Plans are provided for reference, educational, and personal use only

• No guarantees or technical support included

You will receive exactly what is shown in the listing images.

If you have any questions – feel free to ask before purchase.

Interest in the aircraft with wings "tandem" almost completely faded
after the creation of aircraft making and firm "Westland". Yet in
1977, the idea was revived and successfully implemented in the new plane,
called "Quick" - amateur light aircraft designed by Tom Jewett, Gene
Sheehan and Burt Rutan.
As the power plant of the aircraft used two-cylinder
engine "Onan" power of 18 hp (13.2 kW).

The secret of progress on this plane high performance is the use of new
construction materials - fiberglass and foam ensures high quality of the
surface of the aircraft and use very precise laminarizovannye airfoils.
Determine the layout of the aircraft is quite difficult. The wings are almost
identical scope and area, on the "Quick" can be considered in tandem.
At the same time, the designers believe that the aircraft is built in a
"duck", as the elevators are located on the front wing and ailerons -
the back. The same can be considered samole tailless biplane with a very large
negative bias wings horizontally. An unusual feature of the layout is the
location of the aircraft main landing gear wheels in the endings of the lower
(front) wing. Since then, when "Quick" appeared on the market of
amateur aircraft in 1980, total production of these devices has exceeded the
total number of aircraft scheme "tandem", built from the time of
Langley. The success of this machine led to the development of a slightly
larger version with double cabin 0-2, as well as the two-seater

"Dregonflay."

LTH: "Quickie"

Crew: ------------------------------------------------ ---------------- 1

Engine: ------------------------------------- 1 x Onan, 13kVt,

Wingspan: ----------------------------------------------- --- 5.1m,

Length: ------------------------------------------------ ------------- 5.3m,

Takeoff Weight: ----------------------------------------------- - 220kg,

Empty weight: ----------------------------------------------- 110kg,

max. Speed: ------------------------------------------ 203km \ h

cruising speed: -------------------------------- 195km \ h

Ceiling: ------------------------------------------------ -------- 3750m,

Range: ------------------------------------------------ --- 1320km

Attention.

This is
not a physical commodity, it is for digital download. This is the Internet
freely available. If you are unsure do not buy this product.

I trade
information and help solve your problem. Save your time !!!

Buying
these drawings, you build your light aircraft!

I will
post worldwide.

Attention.

For
digital download only, the item physically will not be sent! You accept that
with the purchase!

An
excellent and detailed material to build ultralight

Drawings
aircraft airplanes - Rutan "Quickie".
